High Powered Mains or Solar Energizer: Agri 150

Engineered for high-performance, large-scale electric fencing, the Agri 150 energizer delivers powerful and reliable operation across demanding agricultural applications. It operates directly from mains power or can be configured for solar and battery operation with the optional Agri Box, providing greater flexibility for a wide range of installations.


Agri 150 Instruction Manual
Test Report for Agri 150
Agri Enclosure with Solar Panel

Features:

  • Powers up to 150km / 375 acres / 150 ha (optimal) or 42km / 75 acres / 30ha  (average) of fence wire*
  • Built to withstand harsh weather conditions with built-in lightning protection
  • Control the energizer with the easy-to-use tag, included
  • Maximum output energy: 15J (20J stored energy)
  • Multiple power configurations: mains adaptor or solar with battery (Agri Box sold separately)
  • Flexible mounting options: wall, enclosure or Agri Box
  • Programmable and controllable via the Nemtek Connect app: program, control, and monitor features such as adjustable fence voltage and pulse rate, adjustable energizer fence overload indicators and alarms, accurate battery and fence voltage reporting, battery type selection, safety level control, and battery-saving modes

Specifications:

Weight 6.62 kg
Dimensions

431.54(L) x 280.83(W) x 140(D)mm

Output energy max

15J (stored energy 20J)

Output voltage

8kV
8kV @ open circuit

Power source

Battery 12Vdc
Power supply 12Vdc

IP rating

IP65

Stock CodeDescription
AE-AGRI150High Powered Mains or Solar Energizer: Agri 150
