Merlin Stealth Dual Zone Keypad

The Merlin Stealth dual zone energizer can also be controlled and programmed with the optional LED Merlin Stealth dual zone keypad. The energizer can be installed near the fence and the keypad can be located where it is most convenient for the user.

Installer manual Merlin Stealth M25S, M28S
User manual Merlin Stealth V1.2


  • Up to four keypads can be connected to one energizer
  • The fence voltage outputs can be adjusted using the keypad
  • The siren and gate outputs can be bypassed using the keypad
  • This dual zone keypad can be used with Merlin M28X energizer


Weight 0.202 kg

L130mm X 105mm X H30mm



Power supply

12V (from the energiser)

Stock CodeDescription
EE-M2ZKPMerlin Stealth Dual Zone Keypad
