Undergate HT Cable (U-Series)
The U-Series high voltage insulated electric fencing cable safely carries power from the energizer to the electric fence and can be used to carry the voltage under gates to connect separate fence sections. Suitable for use with galvanised and aluminium wire, poly wire, poly rope, and poly tape.
Features:
- Engineered for demanding environments
- Double insulated UV stabilised outer and inner sheaths
- 6mm diameter inner conductor wire for medium cable runs
- 5mm diameter inner conductor wire for long cable runs and large fences
Specifications:
| Weight | N/A |
|---|---|
| Material | Solid heavy galvanised inner conductor |
| Roll size | 25m |
| Colour | Black |
| Diameter | 1.6mm |
| Resistance | 1.6mm – 98 Ohms/km |
| Stock Code | Description |
|---|---|
| AH-UC1.6/25 | 1.6mm Undergate HT Cable (U-series) 25m |
| AH-UC1.6/50 | 1.6mm Undergate HT Cable (U-series) 50m |
| AH-UC1.6/100 | 1.6mm Undergate HT Cable (U-series) 100m |
| AH-UC2.5/25 | 2.5mm Undergate HT Cable (U-series) 25m |
| AH-UC2.5/50 | 2.5mm Undergate HT Cable (U-series) 50m |
| AH-UC2.5/100 | 2.5mm Undergate HT Cable (U-series) 100m |
| AH-UC2.5/200 | 2.5mm Undergate HT Cable (U-series) 200m |
| AH-UC2.5/500 | 2.5mm Undergate HT Cable (U-series) 500m |
